10Pcs MF117ZZ 7X11X3 mm Miniature Flanged Ball Bearings ABEC-7 MF52ZZ MF115ZZ MF148ZZ MF62ZZ MF93ZZ MF117ZZ MF63ZZ MF95ZZ MF126ZZ

Short Description:

Bearing Type: Flange Ball BearingModel: MF117ZZInner diameter (d): 7 mmOuter dia

CONTACT NOW AliExpress retail store

Product Details

Product Tags

Bearing Type: Flange Ball Bearing

Model: MF117ZZ

Inner diameter (d): 7 mm

Outer diameter (D): 11 mm

Width (B): 3 mm

Flange Structure: Integrated One-piece Flange Rim

Bearing Material: Bearing Steel

Seal Structure: ZZ Double Metal Shielded

Corrosion Resistance: General

Clearance: C0

Grades: ABEC-7

Lubrication: Grease

Key Features: Fast Install, Anti Layer Shift, Vibration Proof, Low Noise, Maintenance Free

Pain Points Solved: No Snap Ring Needed, Lower Machining Cost, No Alignment Errors

Main Application: 3D Printer, Drone, Power Tool, Micro Motor

Product Advantage: High Speed Stable, Space Saving, Simple Design, Shock Proof

Unique Selling Point: Integrated Flange Axial Lock, Eliminate Layer Shift

Premium Bearing Steel Flange Ball Bearings ABEC-7 Precision

Unlock fast installation and rock-solid axial stability with our high-performance flange ball bearings.

•Bearing Steel Construction

Both rings and balls are crafted from GCr15 Chrome bearing steel, delivering excellent hardness, load capacity, and durability for long service life under continuous rotation.

•Integrated One-piece Flange Rim

The built-in flange acts as an axial lock that positively locates the bearing in the housing — no snap rings, washers, or retaining hardware needed. It eliminates layer shift and alignment errors, lowers machining cost, and guarantees square, repeatable mounting every time.

•ZZ Double Metal Shields

Double metal shields on both sides seal out dust, dirt, and debris, protecting internal components for consistent, maintenance-free performance; an open type is also available where internal access or re-lubrication is preferred.

•C0 Clearance & Grease Lubrication

Pre-lubricated with grease and built to C0 standard clearance, providing smooth, quiet rotation right out of the box while simplifying assembly and reducing long-term upkeep.

•ABEC-7 Precision

Precision-ground to ABEC-7 tolerance standards, delivering high rotational accuracy, ultra-smooth operation, low noise, and minimal vibration — ideal for 3D printers, drones,power tools, micro motors, and other compact high-speed assemblies.
